60W Aluminum Switching Power Supply

Starwell is a reputable manufacturer known for producing high-quality 60W aluminum switching power supply. These power supplies are designed to provide reliable and efficient performance for various applications. With their durable aluminum casing, Starwell's switch power supplies offer enhanced protection and longevity.

Features:
Universal input: 100-240VAC 50-60Hz
Output Power: 60W
Output: 12V/5A, 24V/2.5A
Protection: short-circuit, overload
-20～+60℃ Working temperature
High efficiency, long life span, and high reliability
Size: 1107836mm
Warranty: 3 years
Certificate: CE RoHs

Send Inquiry

DATASHEET

Product Details

60W Aluminum Switching Power Supply applications and advantages:

Industrial Automation:

Advantage: The 60w Aluminum Switching Power Supply provides durability and protection in industrial environments, ensuring reliable operation

Applications: It can be used to power control panels, PLCs (Programmable Logic Controllers), and other industrial automation equipment.

LED Lighting:

Advantage: The 60W Switch Power supply offers efficient heat dissipation, preventing overheating and ensuring the longevity of the power supply

Applications: It is suitable for powering LED lighting systems in residential, commercial, and industrial settings.

Telecommunications:

Advantage: The 60W Aluminum Switching Power Supply provides EMI shielding, reducing the risk of interference and ensuring better signal integrity

Applications: It can be used to power routers, switches, modems, and other telecommunications equipment.

Audio/Video Equipment:

Advantage: The 60W power supply enhances safety by providing protection against electrical shock and short circuits.

Applications: It is suitable for powering sound systems, amplifiers, video equipment, and other audio/video devices.

STARWELL 60W Aluminum Switching Power Supply Features:

1. Protection: short-circuit, overload

2. 100% full-load aged

3. Withstand 300VAC surge input for 5 seconds

4. -20～+60℃ Working temperature

5. 5G vibration tested

6. High efficiency, long life span, and high reliability

Applications: Industrial automation machinery、Industrial control system、Testing and measuring instruments、Household appliances、Led lighting appliances、Aging equipment、IT communication equipment

Warranty: 3 years

Certificate: CE RoHs

STARWELL 60W Aluminum Switching Power Supply Specifications:

NAME:	LED POWER SUPPLY, LED DRIVER, LED Switching power supply LED power adapter, Led strip power supply, LED SMPS
Model No.	60W Series	SW-60-12	SW-60-24
Output	DC Voltage	12V	24V
	Current Range	0~5A	0~2.5A
	Power	60W
	Ripple And Noise	Max 240mVp-p
	Voltage ADJ.Range	10~13V	22~26V
	Voltage Tolerance	±5%
	Setup, Rise Time	1500ms, 30ms / 230VAC
Input	Voltage Range	90~260VAC
	Frequency Range	50~60Hz
	Efficiency	>0.85
	PF	0.6
	Current	7A/110VAC, 4A/220VAC
	Surge Current	40A/110VAC, 60A/220VAC
	Leakage Current	Max 3.5mA/240VAC
Protection	Overload	Above 110%-150% of rated power
		Shut-down output voltage, auto recovery after fault condition is removed
	Overvoltage	Above Max. Voltage (105% of rated voltage)
		Shut-down output voltage, auto recovery after fault condition is removed
	Over temperature	90℃ ± 5℃(5~12V) 80℃ ± 5℃(24V)
		Shut-down output voltage, auto recovery after fault condition is removed
Environment	Working Temp. & humidity	"-20°C~+60°C, 20%~90%RH
	Storage Temp. & humidity	"-40°C~+85°C, 10%~95%RH
Safety	Withstand Voltage	I/P-O/P: 1.5KVAC/1min; I/P-F/G: 1.5KVAC/1min; O/P-F/G: 0.5KVAC/1min;
	Safety	GB4943 ;IEC60950-1; EN60950-1
	EMC	EN55032:2015/AC:2016; EN61000-3-2:2014; EN61000-3-3:2013; EN55024:2010+A1:2015
	LVD	EN60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
Other	Cooling	free air
	Lifespan	20000hrs
	Dimensions (LWH)	1107836mm
	Weight	210g
Note	1. The above mentioned data were measured at 230VAC input and 25°C. 2. Dis-connect the AC input before checking any mal-phenomenons. 3. Make sure the INPUT&OUPUT were in right situation before connected to power supply. 4. Datasheet for reference only. We suggest you take sampling before mass orders.
