200W Aluminum Switching Power Supply

Starwell 200W Aluminum Switching Power Supply is a type of power supply unit that provides a maximum power output of 200 watts. It is commonly used in various electronic devices and systems that require a stable and efficient power source. This type of power supply is designed to convert the incoming AC power from the mains into a regulated DC power output.

Features:
Universal input: 100-240VAC 50-60Hz
Output Power: 200W
Output: 12V/16.7A, 24V/8.3A
Protection: short-circuit, overload
-20～+60℃ Working temperature
High efficiency, long life span, and high reliability
Size: 20011050mm
Warranty: 3 years
Certificate: CE, RoHs

Send Inquiry

DATASHEET

Product Details

200W Aluminum Switching Power Supply advantages

Versatility: The 200W Aluminum Switching Power Supply makes it suitable for a wide range of applications, including industrial equipment, telecommunications, networking devices, and more.

Energy Efficiency: 200W Switch power supplies are known for their high energy efficiency, which helps reduce energy consumption and operating costs.

Reliability: These power supplies are designed to provide a stable and reliable power source, ensuring the proper functioning of connected devices.

Compact Design: The compact size of the 200W switch power supply allows for easy installation and integration into various systems and devices.

Features

1. Protection: short-circuit, overload

2. 100% full-load aged

3. Withstand 300VAC surge input for 5 seconds

4. -20～+60℃Working temperature

5. 5G vibration tested

6. High efficiency, long life span, and high reliability

Applications: Industrial automation machinery、Industrial control system、Testing and measuring instruments、Household appliances、Led lighting appliances、Aging equipment、IT communication equipment

Warranty: 3 years

Certificate: CE RoHS

200W Aluminum Switching Power Supply Specifications

NAME:	LED POWER SUPPLY, LED DRIVER, LED Switching power supply LED power adapter, Led strip power supply, LED SMPS, aluminum switch mode power supply
Model No.	200W power	SW-200-12	SW-200-24
Output	DC Voltage	12V16.7A power supply	24V8.3A power supply
	Power	200W led power supply
	Ripple And Noise	Max 240mVp-p
	Voltage ADJ.Range	10~13V	22~26V
	Voltage Tolerance	±5%
	Setup, Rise Time	1500ms, 30ms / 230VAC
Input	Voltage Range	90~260VAC
	Frequency Range	50~60Hz
	Efficiency	>0.85
	PF	0.6
	Current	7A/110VAC, 4A/220VAC
	Surge Current	40A/110VAC, 60A/220VAC
	Leakage Current	Max 3.5mA/240VAC
Protection	Overload	Above 110%-150% of rated power
		Shut-down output voltage, auto recovery after fault condition is removed
	Overvoltage	Above Max. Voltage (105% of rated voltage)
		Shut-down output voltage, auto recovery after fault condition is removed
	Over temperature	90℃ ± 5℃(5~12V) 80℃ ± 5℃(24V)
		Shut-down output voltage, auto recovery after fault condition is removed
Environment	Working Temp. & humidity	"-20°C~+60°C, 20%~90%RH
	Storage Temp. & humidity	"-40°C~+85°C, 10%~95%RH
Safety	Withstand Voltage	I/P-O/P: 1.5KVAC/1min; I/P-F/G: 1.5KVAC/1min; O/P-F/G: 0.5KVAC/1min;
	Safety	GB4943 ;IEC60950-1; EN60950-1
	EMC	EN55032:2015/AC:2016; EN61000-3-2:2014; EN61000-3-3:2013; EN55024:2010+A1:2015
	LVD	EN60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
Other	Cooling	free air
	Lifespan	20000hrs
	Dimensions (LWH)	1999842mm
	Weight	0.48KG
Note	1. The above mentioned data were measured at 230VAC input and 25°C. 2. Dis-connect the AC input before checking any mal-phenomenons. 3. Make sure the INPUT&OUPUT were in right situation before connected to power supply. 4. Datasheet for reference only. We suggest you take sampling before mass orders.
